The CH340 chip is used by a number of Arduino compatible boards to provide USB connectivity, you may need to install a driver, don’t panic, it’s easier than falling off a log, and much less painful.
Windows Drivers and Installation Instructions To use the CP2102 on a computer running Mac OS X, you should download and install the CP210x USB to UART Bridge VCP Drivers from Silicon Labs for Mac OS X. Trying to get the cp210x usb to uart bridge virtual com port vcp driver to install on my windows 7 machine. Silicon laboratories cp210x vcp drivers for windows 2000xp3 - this review pertains to the latest version of the cp210x family of usb to uart bridge virtual com port vcp drivers from silicon labs inc. Cp2102 or usb to the build.
Plu g in your NodeMCU, and head over to the Device Manager. Easy way is to right click on the windows button or press windows key+X. Look for a USB to Serial kind of device that seems to be broken. CP210x USB to UART Bridge VCP Drivers, Silicon Labs. FTDI drivers are available for Windows CE 4.2-5.2, 6.0/7.0 and 2013. Aideepen ESP8266 Serial Wi-Fi Wireless ESP-01. Build-in reset button and Bootloader button. Raspberry Pi, Useful commands DIY Projects. Not to a nodeMCU but to both an ESP8266 - my own board using a CP2104 - and using a cheap CH340G USB to Serial thingy to talk to both a Nextion display and 328P breadboard circuits. We now know what you have, and use, so I am sure some Mac user will be along soon to try and help.
Windows
(Manufacturer’s Chinese Info Link)
- Download the Windows CH340 Driver
- Unzip the file
- Run the installer which you unzipped
- In the Arduino IDE when the CH340 is connected you will see a COM Port in the Tools > Serial Port menu, the COM number for your device may vary depending on your system.
Older Windows Driver Version and Instructions
Download the Windows CH340 DriverUnzip the folder.If you are running a 64Bit Windows: – run the SETUP_64.EXE installer.If you are running a 32Bit Windows: – run the SETUP_32.EXE installer.If you don’t know, try the 64 bit and if it doesn’t work, the 32 bit.In the Arduino IDE when the CH340 is connected you will see a COM Port in the Tools > Serial Port menu, the COM number for your device may vary depending on your system.
Macintosh
(Manufacturer’s Chinese Info Link)
The following github has up to day pkg files for 1.3, 1.4 and 1.5 at time of writing, thanks to Joshua Wallis for bringing this to my attention…
Direct Download Links (from the github repo above):
See the github link above for installation instructions if you need them.
Previous macinstosh downloads if the above doesn’t work for you…
(V1.3) Download the CH340 Macintosh Signed Driver for Mavericks (10.9), Yosemite (10.10) and El Capitan (10.11) and Sierra (10.12)
Inside the zip file you will find a PDF and a “pkg” file, short version, double click the pkg file, the PDF has some extra information.
OSX Sierra (10.12) Note
A kindly user, Maarten Segers reports
FYI, the driver documented here WILL crash on OSX Sierra.
I can personally not test on MacOS and can not vouch for the above drivers at github, but there you go.
Vcp Driver Nodemcu For Mac Download
See uninstalling information at the bottom of the page if the driver causes problems for you.
Here is an older version of the Mac driver, NOT FOR 10.12 Sierra
(V1.0) Download the CH340 Macintosh Signed Driver for Mavericks (10.9), Yosemite (10.10) and El Capitan (10.11)
Linux
Vcp Driver Nodemcu For Mac Os
(Manufacturer’s Chinese Info Link)
Vcp Driver Nodemcu For Mac Torrent
Drivers are almost certainly built into your Linux kernel already and it will probably just work as soon as you plug it in. If not you can download the Linux CH340 Driver (but I’d recommend just upgrading your Linux install so that you get the “built in” one).
Vcp Driver Nodemcu For Mac Windows 7
Uninstalling From Macinstosh
A couple of Mac users have said “the driver crashes my mac Sierra how do I uninstall”.
Firstly regards the crash make sure you installed the 1.3 version of the driver, not the old one. You could download it directly from the Manufacturers Website in case they have issued an update since I wrote this page.
Secondly a quick google search reveals that this is how you uninstall:
- Open a terminal and type:
cd /Library/Extensions/ - Verify that the .kext file is present:
ls | grep usbserial.kext - Output should be:
usbserial.kext - Then type:
sudo rm -R usbserial.kext - Verify that the .kext file has been removed:
ls | grep usbserial.kext - Output should be empty.
- After you should remove the files stored in receipts folder:
cd /private/var/db/receipts/ - Find the enties:
ls | grep usbserial* - Output should be:
codebender.cc.ch34xinstaller.usbserial.pkg.bom codebender.cc.ch34xinstaller.usbserial.pkg.plist - Remove each one of the files of the above list:
sudo rm -rfilename`
